Body, Part and Assembly Drawings
AutoStruct automates the generation of fabrication-ready drawings for all project bodies, complete with customizable templates.
-
Similar bodies within a family are consolidated into a single document, simplifying production.
-
Detailed features include smart dimensioning, hole positions, bend dimensions, and automatically inserted part information.
-
Flexibility in saving drawings: everything in one file, split by part, or organized by maximum sheet count per file. This ensures streamlined production documentation and convenient storage in respective shop folders.
Cut List
AutoStruct streamlines the creation of detailed, error-free cut lists by identifying identical bodies across an entire assembly.
-
Each body is assigned a unique ID and the total count of identical bodies is automatically calculated, preventing duplicate parts from being sent to production.
-
Identical bodies in separate parts are assigned a single ID, ensuring they are counted only once.
-
All bodies are aggregated into a single, organized excel file.
-
Export options include comprehensive sheets for all parts, weldment profiles, plate details and cut lists.
-
Option to exclude selected parts from Cut List data.
DXF File Export
Exporting cutting data to DXF files is quick and efficient with AutoStruct.
-
Plates, including sheet metal and extrudes, can be exported directly from the main assembly with the click of a button.
